DC Motor WSERD50

DC Motor WSERD50 Image

This unit is recommended for use with 50mm DC motors. It’s a solar panel with 4400mAh storage capacity using rechargeable Lithium batteries. The batteries will be fully charged in 80 hours of direct sunlight, and when full, will hold enough charge for about 50 days of normal operation without further charging. In the event that the batteries are depleted by excessive use or poor solar panel positioning, the batteries can be recharged in a few hours by connecting an external charger to the unit.

3rd intermediate limit position

Low power consumption

Soft start and soft stop

Electronic limit switch

Optional power source – TYB002 Solar panel and battery pack. 3m extension cables are available.

120V/60HzType 15/12
Rated Torque (N.m)15
Output Speed (rpm)12
Nominal Consumption (W)96
Nominal Voltage (V)12
Nominal Current (A)8
Protection Index (IP)44
Total Length (mm)565
Maximum Turnsinfinity
Net Weight (kg)2.04



tubular motor compliance
